SWITCH POE TENDA GESTITO L3 TEG5310P-8-150W
Modello: TEG5310P-8-150W
DESCRIZIONE DEL PRODOTTO
SWITCH POE TENDA GESTITO L3 TEG5310P-8-150W è un dispositivo professionale di elevata qualità costruttiva, progettato per garantire massima affidabilità e piena rispondenza agli standard tecnici di settore. Adatto a impianti di sicurezza, telecomunicazioni e automazione sia civili che industriali.
SPECIFICHE TECNICHE
| Marchio / Brand | TENDA |
| Codice Modello | TEG5310P-8-150W |
| Categoria | Switch PoE & Ethernet |
| Network standards | IEEE802.3、IEEE802.3u、IEEE802.3ab、IEEE802.3z、IEEE802.3x、IEEE802.3af/at、IEEE802.1p、 IEEE802.1q、IEEE802.1w、IEEE802.1d、IEEE802.1s |
| LED indicators | One Link/Act or PoE LED indicator for each port One Link/One Link/Act mode converting LED indicator for each device One PoE mode converting LED indicator for each device One PoE Max LED indicator for each device One Power LED indicator for each device One SYS LED indicator for each device |
| Fixed ports | 8 x 10/100/1000 Base-T Ethernet ports (Data/Power) 1 x 10/100/1000 Base-T Ethernet ports (Data) 1 x 1000 Base-X SFP ports (Data) |
| Lightning protection | ≥6 kV |
| Forwarding mode | Store-and-forward |
| MAC address table | 16K |
| PoE power supply | Ports 1 to 8 support IEEE 802.3af/at standard PoE power supply 1 2 4 5 +, and 3 6 7 8 - |
| Input voltage | 100-240V ～ 50/60Hz |
| Dimensions | 294 mm x 179.6 mm x 44 mm |
| Whole switch consumption | Whole switch consumption: |
| Operating environment | Operating temperature: 0°C - 40℃ Storage temperature: -40°C - 70°C Operating humidity: (10% - 90%)RH,non-condensing, Storage humidity: (5% - 90%)RH, non-condensing |
| Software specificationsPoE power supply management | Supports port PoE configuration and power supply with priority Supports PoE over-temperature protection Supports PoE scheduled management Supports intelligent management and PoE-powered device detection (port status, power assignment and PoE-powered device status) |
| Security features | ARP receiving limit Unknown MAC address discard DoS attack defense 802.1x security authentication |
| VLAN | IEEE 802.1Q VLAN VLAN Layer-3 interfaces Supports three port modes: Access, Trunk and Hybrid |
| DHCP | DHCP Server DHCP Relay DHCP Snooping Supports Option 82 policy configuration |
| L3 Routing | VLAN-based routing IPv4 static routing adding Static ARP adding/deleting ARP aging time configuration |
| Port aggregation | Static aggregation LACP dynamic aggregation |
| Spanning tree | IEEE 802.1d STP (Spanning Tree Protocol) IEEE 802.1w RSTP (Rapid Spanning Tree Protocol) IEEE 802.1s MSTP (Multiple Spanning Tree Protocol) Supports edge port Supports BPDU statistics |
| Multicast | IGMP Snooping V1/V2/V3 Supports port fast leave |
| Port Mirroring | Supports N: 1 porta mirroring |
| QoS | SP (Strict Priority) SWRR (Simple Weighted Round Robin) WRR (Weighted Round Robin) Supports 802.1p port trust mode Supports DSCP port trust mode Supports a maximum of 8 queue service quality mapping |
| ACL | Supports MAC ACL and IP ACL |
| Loading and upgrade | Supports FTP/TFTP/HTTP upgrade Supports configuration import and export |
| Management and maintenance | Supports Telnet, Console Supports SNMP V1/V2/V3 Supports WEB management and maintenance Supports Ping/Tracert/Connection Detection |
| Certificates | CCC、FCC、CE、RoHS |
GARANZIA E CONFORMITÀ
Prodotto originale coperto da Garanzia Ufficiale del Produttore di 24 Mesi. Conforme alle direttive europee di sicurezza (CE, RoHS).
