Hikvision DS-3E1505P-EI/M
Modello: DS-3E1505P-EI/M
DESCRIZIONE DEL PRODOTTO
Hikvision DS-3E1505P-EI/M è un dispositivo professionale di elevata qualità costruttiva, progettato per garantire massima affidabilità e piena rispondenza agli standard tecnici di settore. Adatto a impianti di sicurezza, telecomunicazioni e automazione sia civili che industriali.
SPECIFICHE TECNICHE
| Marchio / Brand | HIKVISION |
| Codice Modello | DS-3E1505P-EI/M |
| Categoria | Switch PoE & Ethernet |
| Rivestimento | Metallo material |
| Peso netto | 0.26 kg (0.573 lb) |
| Peso lordo | 0.75 kg (1.65 lb) |
| Dimensioni (largh. × alt. × gl.) | 121.1 mm × 27.6 mm × 83.1 mm (4.77'' × 1.09'' × 3.27'') |
| Temperatura di esercizio | 0 °C to 40 °C (32 °F to 104 °F) |
| Temperatura di stoccaggio | -40 °C to 85 °C (-40 °F to 185 °F) |
| Umidità in esercizio | 5% to 95% (no condensation) |
| Umidità wzgledna | 5% to 95% (no condensation) |
| Alimentatore | 54VDC, 0.92A |
| Modalità di installazione | Desk-Mounted,Wall-Mounted |
| Consumo energetico max. | 50 W |
| Consumo energetico su biegu jalowym | 1 W |
| Protezione przeciwprzepieciowa | 6 KV |
| Parametroy di rete | Porte4 × Gigabit PoE port,1 × Gigabit RJ45 port |
| Tabela indirizzi MAC2 K | |
| Capacità przelaczania10 Gbps | |
| Velocità przekazywania pacchetti7.44 Mpps | |
| da interno memoria podmanuale1 Mbits | |
| Alimentazione PoE | Standard PoEIEEE 802.3af,IEEE 802.3at |
| Pin di alimentazione PoEEnd-span: 1/2(-), 3/6(+) | |
| Porta PoEPoE: Ports 1 to 4 | |
| Max. moc portu30 W | |
| Budget di potenza PoE45 W | |
| funzionalità oprogramowania | Daleki zasiegPorts 1 to 4: up to 300 m. Long range performance may vary depend on camera model or cable condition. |
| Isolamento delle portePorts 1 to 4: port isoanniion mode to improve network security Ports in an isoanniion group cannot communicate with each other, but they can communicate with ports outside the isoanniion group. | |
| Watchdog PoEPorts 1 to 4: auto detect and restart the cameras that fino a not respond. | |
| Agregacja laczyLink aggregation is used to aggregate multiple physical ports to form a logical port for load balancing, bandwidth expansion, and port protection. Support static link aggregation. Support 1 aggregation groups. | |
| Zapobieganie petlomLoop prevention is used to prevent the switching network from forming loops, which will seriously affect network communication. Disabled by default. Support 802.1D STP. Suppport 802.1w RSTP. | |
| VLANVLAN is used for network sinteri planning and network health improvement. Support 802.1Q. Configurable VLAN ID from 1-4094. Support Trunk, Access port mode. Support Max. 32 VLAN. | |
| HPPSupport one-click activation and remote management via Hik-Partner Pro. Functions supported: 1. Display the port rate. 2. Display the port bandwidth utilization rate. 3. Display the PoE power usage. 4. Display topology information. 5. Display the alarm status. 6. Restart ports and devices. 7. Enable port long-rage mode. 8. Remotely upgrade the device. | |
| Konserwacja del sistemaSupport device management via web. Support DHCP Client. Enabled by default for dynamic assignment of management IP addresses. Support Super IP, which is a fixed IP address (10.180.190.200) for direct access. Support management via Hik-Central Pro. Support remote management via Hik-Partner Pro. Support cable detection. Abnormal open circuits and short circuits as well as network cable length can be detected. Supports 802.1ab LLDP for peer device discovery. Support port mirroring for fault locating. | |
| Normative | EMC (kompatybilnosc elektromagnetyczna)CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020) |
| SicurezzaCB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017) | |
| Prodotti chimiciCE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Reguanniion (EC) No.1907/2006) |
GARANZIA E CONFORMITÀ
Prodotto originale coperto da Garanzia Ufficiale del Produttore di 24 Mesi. Conforme alle direttive europee di sicurezza (CE, RoHS).
